NOx Emissions: Consistently below 30mg/Nm³.
Compact Integrated Design, Small Size, High
Technical Features:
※ Proportional control operation mode.
※ Equipped with an automatic P.I.D controller for proportional control operation. (Control components are ordered separately.)
※ Control Method: Electronic proportional control / Mechanical proportional control.
※ Independent servo motor adjusts the air damper opening.
※ The air damper automatically closes during pauses to reduce heat loss in the furnace.
※ Independent servo motors control fuel, air flow, and flue gas flow separately.
※ Air pressure switch ensures the presence of combustion air. UV flame detection.
※ Control panel complies with EN298 standards.
※ Programmable controller includes built-in valve leak detection.
※ Pipeline position: Upward or downward.
※ Fan motor meets European IE3 standards.
※ Electrical protection rating: IP40.
