factory Outlets for Api 5l X70 Steel Line Pipe Uoe - uni 2276-67 2277-67 2278-67 flat flange for welding – TOP-METAL Detail:
Quick Details
- Size: DN15-DN1600
- Material: carbon steel or stainless steel
- Standard: UNI
- Place of Origin: Hebei, China (Mainland)
- Model Number: PLATE FLANGE
- Brand Name: TM
- Standard or Nonstandard: Standard
- item: uni 2276-67 2277-67 2278-67 flat flange for welding
- Surface: Anti-rust Oil
- Flange facing: RF
- Technics: Forged
Packaging & Delivery
Packaging Details | uni 2276-67 2277-67 2278-67 flat flange for welding: In ply-woonden case or pallet. |
---|---|
Delivery Time | Shipped in 30 days after payment |
Pressure:
PN6, PN10, PN16, PN25, PN40, PN64, PN100
PN6(UNI2276-67 UNI6088-67 UNI2280-67 UNI2253-67 UNI6091-67)
PN10(UNI2277-67 UNI6089-67 UNI2281-67 UNI2254-67 UNI6092-67)
PN16(UNI2278-67 UNI6090-67 UNI2282-67 UNI6093-67)
PN25(UNI6083-67 UNI2299-67 UNI2283-67 UNI6094-67)
PN40(UNI6084-67 UNI2300-67 UNI2284-67 UNI6095-67)
PN64(UNI2285-67 UNI6096-67*)
PN100(UNI2286-67 UNI6097-67*)
Size: DN10 - DN2000
Type: FF, LJ, WN, TN-RF(THREAD NECK), BL
Material: Rst37.2, Stainless steel 304/304L/316/316L
Processing technic: Forging or Casting.
Packing: Poly wooden case or Pallet
Surface treatment: Rust-preventative oil, Painted
Directions for the designation |
D1 |
a |
b |
d |
f |
Number of holes |
Threading of the screws |
weight |
||
Rated Diameter |
External diameter of the pipe |
Nominal |
Tolerance |
Kg |
||||||
15
|
20 |
20.5 |
+0.5 |
65 |
12 |
95 |
14 |
4 |
M12 |
0.67 |
21.3 |
22 |
0.66 |
||||||||
20 |
25 |
25.5 |
75 |
14 |
105 |
14 |
|
M12 |
0.83 |
|
26.9 |
27.5 |
0.82 |
||||||||
25 |
30 |
30.5 |
85 |
14 |
115 |
14 |
4 |
M12 |
1.03 |
|
33.7 |
34 |
1.01 |
||||||||
32 |
38 |
38.5 |
100 |
16 |
140 |
18 |
4 |
M16 |
1.66 |
|
42.4 |
43 |
1.63 |
||||||||
40 |
44.5 |
45 |
110 |
16 |
150 |
18 |
44 |
M16 |
1.89 |
|
48.3 |
49 |
1.85 |
||||||||
50 |
57 |
58 |
125 |
18 |
165 |
18 |
4 |
M16 |
2.51 |
|
60.3 |
61.5 |
2.46 |
||||||||
65 |
76.1 |
77 |
145 |
18 |
185
|
18 |
4 |
M16 |
3.00 |
|
80 |
88.9 |
90 |
160 |
20 |
200 |
18 |
8** |
M16 |
3.61 |
|
100 |
108 |
109 |
+1.0 |
180 |
22 |
220 |
18 |
8 |
M16 |
4.60 |
114.3 |
115.5 |
4.40 |
||||||||
125 |
133 |
134.5 |
210 |
24 |
250 |
18 |
8 |
M16 |
6.19 |
|
139.7 |
141 |
5.92 |
||||||||
150 |
159 |
160.5 |
240 |
24 |
285 |
22 |
8 |
M20 |
7.63 |
|
168.3 |
170 |
7.17 |
||||||||
175 |
193.7 |
195.5 |
270 |
26 |
